Roller Bearing Housing TK6204-89 Hot Sale Belt Conveyor Roller Accessory China Factory Supply
| Model | Specification | Flange mm | Bearing seat dia mm | Caliber mm | Hole mm | Deep dia mm | Height mm | Thickness mm |
| TK | 6204-89 | 84 | 47 | 47.1 | 25 | 45 | 47.5 | 3 |
| TK | 6204-108 | 103 | 47 | 47.1 | 25 | 45 | 47.5 | 3 |
| TK | 6204-133 | 128 | 47 | 47.1 | 25 | 45 | 47.5 | 3 |
| TK | 6204-159 | 153 | 47 | 47.1 | 25 | 45 | 48 | 3 |
| TK | 6205-89 | 84 | 52 | 52.1 | 30 | 46 | 48.5 | 3 |
| TK | 6205-108 | 103 | 52 | 52.1 | 30 | 46 | 49 | 3 |
| TK | 6205-133 | 128 | 52 | 52.1 | 30 | 46 | 49 | 3 |
| TK | 6205-159 | 153 | 52 | 52.1 | 30 | 46 | 49 | 3 |
| TK | 6305-108 | 103 | 62 | 62.1 | 35 | 49 | 52 | 3 |
| TK | 6305-133 | 128 | 62 | 62.1 | 35 | 49 | 52 | 3 |
| TK | 6305-159 | 153 | 62 | 62.1 | 35 | 49 | 52 | 3 |
| TK | 6306-108 | 103 | 72 | 72.1 | 40 | 51 | 54 | 3 |
| TK | 6306-133 | 128 | 72 | 72.1 | 40 | 51 | 54 | 3 |
| TK | 6306-159 | 153 | 72 | 72.1 | 40 | 51 | 55 | 4 |
| TK | 6307-133 | 128 | 80 | 80.1 | 45 | 53 | 57 | 4 |
| TK | 6307-159 | 153 | 80 | 80.1 | 45 | 53 | 57 | 4 |
Bearing Housing Specification
Product Features:
Roller Model: TK, TKII, DTII, TD75
Bearing Type: 6203,6204,6205,6206,6305,6306,6307,6308,
6309, 6310.etc.
Roller Diameter:63,76,89,103,108,114,127,133,159,165,176,
194, 219,etc.
Material:
1. Bearing Housing: Carbon steel SPHC from Baosteel Group
2. Inner Sealing Ring: Nylon PA6
3. Male/Female Labyrinth Seal: POM
4. Cover Cap: Carbon Steel SPCC
5. Protective Shield: Nylon PA6
Product (TK Series Bearing Housing and Seals):
Our roller bearing housing and the relative seals have the advange of high precision, good gloss,
without stretching scars or burrs. Steel materials are from Shanghai Baosteel Group, which is the best steel
maker in China.
Factory Show:
Our factory are professional in manufacturing & exporting bearing housing and seals for more than 15 years,
and is approved by ISO9001-2008 quality management system. We have 4 advanced production lines which
make us the largest and most professional bearing housing maker in China.
Packing:
Usually, our bearing housing and seals are packed in wooden case. Of course, we could also packed the items
as requested.
Customer Visiting:
Our business has been extended to over 30 countries over the world such as Russia, USA, Netherlands,
Chile, Mexico, Colombia, Thailand, Indonesia.,etc.
Welcome to visit our factory, and we promise to provide you with our best products and services.
Our Advantages:
1. Automatic production and advanced inspection machine have been controlling a low tolerance which
make your assemble process easiler.
2. Best raw material will create a better operating environment and bring a longer service life for bearings.
3. With a best operating status of bearing, rollers will keep running under low resistance, which will minimize
the abrasion to the conveyor belt.
4. Working under low resistance also saves a mass of electric energy.
5. The carrying material will not spill out or drop down easily with a small axial and radial runout.
